GE India Industrial

• New line of Air Circuit Breakers
• Evolved from Global platform
• Adapted for Indian conditions
• Manufactured in India
• Range & Performance:
• 630A - 6400A in 3 frame sizes
• Conforms to IEC60947-2/3
• 3P & 4P versions and Fixed & Withdrawable configurations
• Choice of 50kA, 65kA, 85kA & 100kA breaking capacities
• Suitable for upto 1000VAC and 750VDC
• Selection-friendly:
• Icu=Ics=Icw=1 second across the range
• Supports complete system selectivity- Selectivity upto a factor of 1.6
• Micro-processor based trip units offer accuracy, reliability and comprehensive
• system protection
• Continuous rated accessories-Simple, flexible and reliable interlocking schemes
• Communication on Modbus/Profibus protocol

• Installation-friendly:
• Compact foot-print
• No deration upto 50°C
• Wider terminals with liberal interphase clearance-Supports termination of aluminium links
• Modular configuration of breaker and accessories
• Control connections accessible from front
• Site-configurable terminals-Quick conversion from Horizontal to Vertical termination and vice versa
• Front-mounted, snap-fit electrical accessories
• Accessories & control voltage indication on front fascia
• Usage-friendly:
• RELT (Reduced Energy Let Through) ensures operator & system safety
• Standard Current metering on large LCD display
• Programming of trip unit through touch-pad
• Standard Event-logger and Fault history
• Cluster-contacts on withdrawable part of ACB facilitates safe& quick maintenance
• Replaceable arcing contacts- Easy & economical method to enhance electrical life

M-PACT MPro AIR CIRCUIT BREAKERS

• Rating 400A – 4000A
• Compliance to IEC 60947-2
• Breaking capacities 50, 65, 80kA (ICS=ICU=ICW)
• Full certification to ASTA, KEMA, LOVAG
• Microprocessor based trip units - MPro27/MPro50 releases (with display as standard)
• Modbus communication in MPro50
• Unique ground fault protections - UEF/REF/SEF in MPro50
• Ground fault minimum setting 10% of In
• Unique Reduced Energy Let Thru feature (RELT) in MPro50
• High electrical & mechanical life
• Complete range of accessories
• Download Brochure

GE RAPID HIGH SPEED DC CIRCUIT BREAKERS

• Ratings 2600A, 4200A, 6000A, 8000A Single Pole
• Reference standards IEC 50123 & IS 60547
• Rated voltage up to 3900V DC
• Compact enclosed construction
• Breaking capacities up to 100 kA
• Direct acting instantaneous and adjustable trip unit operates without external power
• High speed opening < 5msec
• Flexible termination
• Suitable for wiring, excitation system, traction applications
• Range of accessories shunt, no volt coil, auxiliary contacts, position indication, plug-in connectors
• Download Brochure
