Kirloskar Electric Company Limited
KIRLOSKAR ELECTRIC COMPANY is one of the leading Indian electrical engineering companies.
Established in 1946, KIRLOSKAR ELECTRIC was the catalyst for industrialization in India.
WE, SABARI MARKETING SERVICES ARE THE AUTHORISED DISTRIBUTORS FOR KIRLOSKAR ELECTRIC A C MOTORS.
AC Motors
Low Voltage Motors: Rerolling Mill Duty Motor
Low Voltage Motors: Rerolling Mill Duty Motor
Low Voltage Motors: Rerolling Mill Duty Motor
Low Voltage Motors: Rerolling Mill Duty Motor
Low Voltage Motors: Wound Open Type Series
Low Voltage Motors: Wound Close Type Series
Low Voltage Motors: Flame Proof Series
Low Voltage Motors: Crane Duty Cage Motors
Low Voltage Motors: Vertical Hollow Shaft Motors
AC Motors
RAVI SERIES MOTORS
-
Unique Features of Ravi Series Motors
-
New Design With Top Terminal Box
-
Side terminal box option available. Terminal box position can be changed at site
-
Dual Mounting From Frame 63 to 315 (S & M)
-
Bolting arrangement to fix end covers -New Design With Bolt Arrangement -Gives more rigidity
-
Terminal box size in 160 frame increased to that of 180 frame-New Design With 180 Terminal Box - Higher cable size can be accommodated
-
Sealed bearing arrangement for frames 63 to 225. ( 180, 200 & 225 frame added compared to earlier series
-
Nylon fans in 250, 280 & 315 frame -Light weight fan and improved cooling
ENERGY EFFICENT MOTORS IE2 & IE3
IE2 level efficiency as per IS 12615 – 2011 and IEC 60034-30
Class "F" insulation with class "B" temperature rise limit.
High starting and pull-up torques to accelerate the load.
Robust and shock resistant stator construction with optimally designed ribs for cooling.
Die-cast aluminum rotors designed to withstand the severe forces encountered during starting.
Terminal box located at RHS from driving End.
Large terminal boxes with sufficient electrical clearances and improved aesthetics.
Optimum fan design for better cooling & minimum energy consumption.
For more technical details, please click here
